Wedge Wrapped V Belt 3V 5V 8V SPZ SPA SPB SPC

Wedge Wrapped V Belt 3V 5V 8V SPZ SPA SPB SPC

Product Item：3V 5V 8V SPZ SPA SPB SPC

V BELT

AUTOMOTIVE V BELT

FAN BELT

MOTOR BELT

Description

Features of FRK POWER's V-belt:

Structure

Name	Function	Material
Outside Fabric	Protect the tensile member	Polyester Cotton Canvas
Tensile Member	Core material to pass the dynamic force	Polyester Wire
Top Rubber	Maintain the top shape of the adhesive tape	NR、CR、SBR
Button Rubber	Support and protect the adhesive force of the tensile member	NR、CR、SBR
Button Rubber	Maintain the bottom shape of the adhesive tape	NR、CR、SBR

· The wrapper protects the inner layer, strong durability.
· Special core rubber used, small elongation and long service life
· Excellent heat-resistance, oil-proof, and wearing resistance
· Prevent the generation of the static and keep safe use
· Small friction coefficient and large transmission effect during operation

· Less noise during operation

Size of Section

Type	Top width	Belt Thickness	Angle	Production scope inch
SPZ	10	8	40	15-120
SPA	13	11	40	18-360
SPB	17	14	40	22-550
SPC	22	19	40	33-600
3V	9.5	8	40	15-120
5V	16	13.5	40	22-550
8V	25.5	23	40	33-600
