Belt characteristics
-
Pitch:
- T (2,5 – 5 – 10 – 20) | AT (3 – 5 – 10 – 20) | SAT (10)
- TK5-K6 – TK10-K6 – TK10-K13 (SELF CENTERING) | ATK5-K6 – ATK10-K6 – ATK10-K13 (SELF CENTERING)
- MXL – XL – L – H – XH
- HTD (3 – 5 – 8 – 14) | RTD (5 – 8 – 14) | STD (5 – 8 – 14)
- EAGLE (5 – 8 – 10 – 14)
- FLAT (1 – 2 – 2,5 – 3 – 9)
- POLY-V K
- T10 – AT10 – HTD8 – Total Protection | TT5
- Double sided tooth construction available
- Antistatic properties according to ISO 9563
- Certified to be according RoHS 2011/65/UE
- Working temperatures between: -25°C to + 80°C
- Tension cords: steel with high tensile strength (Special cords on request)
- Compound: thermoplastic polyurethane 92 Sh. A with high wear resistance
